High-Brightness High-Protection｜Easy Installation｜Energy-Efficient Stable Operation ｜Comprehensive Post-Purchase Support
| Model | O-1531FG | O-2525F | O-H2550FG | |
| Pixel pitch:
Inside the light blade Between light blades |
15.625 mm
31.25 mm |
25mm
25mm |
25mm
50mm |
|
| Direction | Vertical | Horizontal / Vertical | Horizontal | |
| Diode Type | DIP | |||
| Pixel density | 2048 dot/sqm | 2048 dot/sqm | 800 dot/sqm | |
| Panel resolution | 16 x 64 dot，Total：1024 dot | 48 x 20 dot；total：960 dot（H）
20 x 48 dot；total：960 dot（V） |
48 x 10 dot；total：480 dot | |
| Panel Size | 500 x 1000 x 138 mm | 1200 x 500x 138 mm （H）
500 x 1200x 138 mm （V） |
1200 x 500x 138 mm | |
| Transparency | 67% | 52% | 72% | |
| Weight | 8 Kg（16.0 Kg/sqm） | 10 Kg（17.0 Kg/sqm） | 7 Kg（12 Kg/sqm） | |
| Installation | Front or Rear installation | |||
| Maintenance | Front or Rear maintenance | |||
| Material | Aluminum profiles & PC mask（Customized colors are available） | |||
| Brightness | 8000 nit | 10000 nit | 10000 nit | 10000 nit |
| Gray scale | 16 bit | 16 bit | 16bit | |
| Viewing Angle（H / V） | 105°/55° | 90°/45° | 90°/45° | 90°/45° |
| Refresh Rate | 3840 Hz | 3840 Hz | 3840 Hz | |
| Video Frame Rate | ≥ 60 Hz | ≥ 60 Hz | ≥ 60 Hz | |
| Input Power <Max> | 500 W/sqm | 425 W/sqm | 425 W/sqm | 320 W/sqm |
| Input Power <Typical> | 167 W/sqm | 142 W/sqm | 142 W/sqm | 107 W/sqm |
| IP rating | IP65 | |||
| Operating Temperature/Humidity | Temperature：-30℃ to 50℃；Humidity：10% – 90% | |||
